Options
• Electric brakes, rear axle.
• Electric breakaway switch with battery.
• 10 lb. fire extinguisher.
• Strobe light.
• Slow moving vehicle sign.
• Flashing arrow stick traffic advisor with controller.
• 200,000 BTU hand held propane torch kit.
• Additional propane bottle holder.
• Hydraulic surge brakes.
• 30-gallon non-heated or propane heated tack tank with automatic temperature control.
• Extended trailer with storage area for compactor plate.
• 8 gallon rinse tank.
• Tool box.
• LED trailer lights.
• Spare tire and rim assembly.
• Engine cover for engine.
• Additional propane bottle holder.
FEATURES & BENEFITS
Specifications HMT4000T/AD HMT6600T/AD
Shipping Weight 4,350 lb (1973 kg) 5,650 lb (2562 kg)
Capacities
Hot Mix Chamber 4,000 lb (1814 kg) 6,600 lb (2994 kg)
Dimensions
Overall Length 186” (472 cm) 210” (83 cm)
Overall Width 80” (203 cm) 86” (218 cm)
Overall Height (closed) 73” (185 cm) 86” (218 cm)
Hopper Opening 72” L x 69” W 90” L x 79” W
Top Loading Doors 78” L x 25” W (2) 92” L x 31” W
Unloading Gate 6” Diameter 6” Diameter
Shoveling Platform 30” W x 18” D 20” W x 18” D
Burners 300,000 BTU vapour (2) 200,000 BTU
vapour propane burner with propane burners with automatic temperature automatic
temperature control. control.
Engine 9hp Honda 25hp Kohler
propane
Controls
Auger Dispensing System Hydraulic Hydraulic
Top Loading Doors Manual Hydraulic
Anti-Bridging Device N/A Hydraulic
Vat Insulation 1” ceramic 2” fiberglass
Brakes Electric Electric
Axle Heavy-duty tandem Heavy-duty
tandem
Capacity 10,400 lb (4727 kg) 14,000 lb (6350
kg)
Tires (4) 225/75R15 (4)
235/86R16
• Heavy-duty channel iron frame.
• Industrial tandem axles complete with slipper spring suspension and electric brakes.
• Adjustable pintle hitch complete with 3” pintle eye and safety chains.
• Heavy-duty screw type swivel trailer jack.
• Fully insulated compartments and loading doors to minimize heat loss.
• Loading doors act as a loading chute.
• All controls are hydraulic; top loading doors (HMT6600T/AD), auger driven material discharge,
and material anti- bridging system (HMT6600T/AD).
• Rear mounted material temperature thermometer with protective hood.
• Vapour propane burner(s) with automatic temperature control and flame-out protection.
• Heating system controls contained in a weatherproof box with quick access latches.
• Rainproof exhaust stack.
• All necessary stop, turn and marker lights.
• Units receive epoxy primer coat prior to finish coat.
• Standard paint color epoxy is blue.
