A-500 Melter
|
|
Manufacturer: A&A Melters
|
The A-500 is our newest addition, with a 500 Gallon capacity its the biggest Rubberized Asphalt Melter on the market.
- Stainless steel fire tubes come standard.
- Front mounted burners.
- Hassle free Material spout at rear.
- Dual loading doors.
- Patented “air-jacketed design”
- No more messy heat transfer oils.
- Heats material in as little as 75 minutes.
- Electric brakes come standard.
- Tandem axle standard.
- NEW-Heavy Duty trailer mounted lifting lugs Standard
SPECIFICATIONS: A-500
|
|---|
| Heat Transfer Oil |
None Required |
| Fire Tubes |
5″ sch 80 Stainless Steel Pipe |
| Capacity |
480 US Gallons |
| Agitator |
Honda 9.0 H.P. Air-Cooled Engine or Optional Diesel Engine |
| Overall Dimensions |
L-192″ W-80″ H-70″ 4,800 lbs |
| Burner |
Adjustable Liquid Propane 2 X 750,000 BTU or Optional Beckett Diesel Burners |
| Temperature Controls |
Optional |
| Inner Shell |
1/4″ Rolled Steel |
| Outer Shell |
3/16″ Rolled Steel |
| Insulated jacket |
1″ Super High Temp. plus 2″ High Temp. |
| Suspension 4″ Drop Axle |
Tandem Axle – 2 x 6000 lb Axles |
| Brakes |
Electric Standard |
| Tow Hitch |
As ordered c/w safety chain |
| Shipping Weight |
4,800 lbs |
| Pump |
Optional 2″ Viking |
| Horizontal Wand Pumping System |
Optional |
| Tires |
4 X 8.00 X 16″ 10 Ply Rating |
| Chassis |
6″ Steel Channel |
| Tandem Axle |
Standard |
Heated Material Output:
- Efficiency: 85.0%
- Heat up time: 60 min
- Material Capacity: 480 US Gallons | 480 gal/1 hr x 88% = 425 gal/hr.
|
|
|
